SIHF GLP Dingzun Cable 3 Core Silicone Insualted Sheathed Multi Core Cable Armored Screen Cable

Name: SIHF GLP Dingzun Cable 3 Core Silicone Insualted Sheathed Multi Core Cable Armored Screen Cable
Brand: Dingzun
Price: 0.25 USD

Quality SIHF GLP Dingzun Cable 3 Core Silicone Insualted Sheathed Multi Core Cable Armored Screen Cable for sale

Brand Name : Dingzun

Model Number : y-25

Certification : ul

Place of Origin : China

MOQ : 200m

Price : USD 0.25-2.5

Payment Terms : T/T, L/C

Supply Ability : 2000M/DAY

Delivery Time : 15DAYS

Packaging Details : ROLL

Conductor : Tinned copper

Construction : 3*14awg

Insulation : silicone

shield : NO

Armor : STAINLESS STEEL

SHEATH : SILICONE

Temperature : 200C

Voltage : 450/750V

Packing : 100M/ROLL

Application : HEATERS CABLE

Contact Now

Y-25

Details:SIHF GLP

Description: 3 core silicone flexible cable with stainless steel braid screen
Conductor: tinned copper
Construction: 3x14awg
Insulation: silicone rubber
Jacket: silicone rubber
Screen: Stainless Steel Braid

PRODUCT SPECIFICATION

AWG	No. of Cores	Conductor cross section mm^2	Nominal OD mm	Copper weight kg/km	Gross Weight kg/km
18	2	0.75	7.2	14.4	88
18	3	0.75	7.6	21.6	99
18	4	0.75	8.1	29	121
18	5	0.75	9.2	36	147
18	6	0.75	9.9	43	169
18	7	0.75	9.9	50	178
17	2	1	7.6	19	98
17	3	1	8	29	119
17	4	1	8.8	38	139
17	5	1	9.7	48	167
17	6	1	10.4	58	185
17	7	1	10.4	67	194
16	2	1.5	8.3	29	126
16	3	1.5	8.7	43	143
16	4	1.5	9.6	58	170
16	5	1.5	10.4	72	198
16	6	1.5	11.4	86	245
16	7	1.5	11.4	101	256
16	8	1.5	12.7	116	315
16	10	1.5	14	144	370
16	12	1.5	14.5	173	408
16	14	1.5	15.6	202	471
16	16	1.5	17	231	541
16	18	1.5	17.8	260	599
16	20	1.5	18.3	288	630
16	24	1.5	20.4	346	760
14	2	2.5	9.7	48	165
14	3	2.5	10.2	72	238
14	4	2.5	11.5	96	268
14	5	2.5	12.7	120	315
14	6	2.5	13.7	144	370
14	7	2.5	13.7	168	385
14	12	2.5	17.6	288	608
12	2	4	11.5	77	255
12	3	4	12.2	115	299
12	4	4	13.4	154	365
12	5	4	15.1	192	455
12	6	4	16.4	230	525
12	7	4	16.4	269	556
10	2	6	12.9	115	326
10	3	6	13.7	173	401
10	4	6	14.8	230	485
10	5	6	16.8	288	602
10	6	6	18.2	346	701
10	7	6	18.2	403	736
8	2	10	17.3	192	543
8	3	10	18.4	288	652
8	4	10	20.6	384	825
8	5	10	22.5	480	987
6	2	16	20.2	308	748
6	3	16	21.5	462	909
6	4	16	23.4	616	1183
6	5	16	26.2	770	1393
4	2	25	23.8	480	1046
4	3	25	26	720	1347
4	4	25	28.3	960	1678
2	2	35	27.2	672	1378
2	3	35	29	1008	1846
2	4	35	32.3	1344	2240
1	2	50	31.4	960	1869
1	3	50	33.5	1440	2384
1	4	50	37.2	1920	2702
2/0	2	70	35.3	1344	2482
2/0	3	70	38.3	2016	3314
2/0	4	70	42.5	2688	4074
3/0	2	90	41.4	1824	3380
3/0	3	90	44.8	2736	4299
3/0	4	90	49.8	3648	5339
4/0	3	120	48.8	3465	5277
4/0	4	120	54.1	4620	6571

This is a Canadian client custom cable, which needs screen in stainless steel wire braid, this buyer is a manufacturer for plastic heaters, so he was very strict for the heat resistance performance., Dingzun team make a design with outer protection in stainless steel wire braid, which can protect the cable from high temperature, although silicone insulation and silicone jacket can bear 200 degree, client need additional protection with outer screen.

The finished cable can bear 400 degree temperature, and considering the silicone material is easy to be scratched, the stainless steel screen can effectively protect the jacket. Meanwhile, the screen can shield unnecessary signal interferences.
